-20-
Control Panel Parts
Key No Service parts No Description Spec. Q’ty
1 617 227 4218 P.C.B COMP. CONTROL C-BOARD 1
2 617 219 6299 P.C.B COMP. SWITCH SW-BOARD 1
3 617 227 6939 CONTROL PLATE SUS430 HL#150 T0.4 1
4 617 219 7180 CONTROL PLATE PMMA 1
5 617 220 2365 CONTROL PLATE 1
6 617 219 7296 ORNAMENT PLATE SUS430 2BC T0.3 1
7 617 219 7289 ORNAMENT PLATE SUS430 2BC T0.3 1
8 617 220 2372 KNOB BODY 1
9 617 219 7203 CONTROL BASE PC+ABS(S1500V) 1
10 617 219 7258 SWITCH BUTTON PET+ABS 1
11 617 220 2389 SWITCH BUTTON ABS 1
12 617 220 2396 FLAT CABLE UL20706 L170 20PBNCD 1
Parts marked with this sign have special
Characterstics important for microwave leakage.
When replacing any of these parts use only
Manufacturers specified parts.
To Next Page
