Sanyo LCD-32XA2 - Chassis Electrical Parts List

-18-
N2YW
OUT OF CIRCUIT BOARD
MISCELLANEOUS
EL901 645 075 1905 LCD(V320B1-L01 REVC2)
645 079 6494 LCD(V320B1-L01 REVC3)
FN902 645 068 3763 MOTOR,FAN DC
K8D-KD 645 078 3920 FLEXIBLE FLAT CABLE
K8J-A 645 040 3002 CORE,FERRITE
KLP2-PN 610 322 8389 CORD 30P 1.25MM(LVDS)
SP901 652 001 4473 SPEAKER,8
SP902 652 001 4473 SPEAKER,8
W900 645 012 7632 ASSY,CORD,POWER
W900-A 645 020 3640 CORE,FERRITE
610 322 3810 ASSY,PWB,SIGNAL,N2WW
1AA0B10N137LA
TRANSISTOR
Q001 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q002 405 118 5729 TR 2SD2198-R-DL
Q003 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q004 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q1003 405 134 5925 TR 2SA1037AK-T146-R
405 147 2215 TR 2SA1037AK-S-T146
405 002 0318 TR 2SA1037K T146 R
405 002 0417 TR 2SA1037K T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
405 173 9615 TR 2SA1235A1E
405 173 9714 TR 2SA1235A1F
Q1004 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
!
!
!
Chassis Electrical Parts List
Ref. No. Part No. Description Ref. No. Part No. Description
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following parts
list be used for components replacement pointed out by the mark.
!
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A : Not specified B : ±0.1pF C : ±0.25pF
D : ±0.5pF F : ±1PF G : ±2pF
R : ±0.25-0pF S : ±0-0.25pF E : +0-1pF
More than 10pF
A : Not specified B : ±0.1% C : ±0.25%
D : ±0.5% F : ±1% G : ±2%
H : ±3% J : ±5% K : ±10%
L : ±15% M : ±20% N : ±30%
P : +100-0% Q : +30-10% T : +50-10%
U : +75-10% V : +20-10% W : +100-10%
X : +40-20% Y : +150-10% Z : +80-20%
Rated value: P=pico farad, U=micro farad
Material:
CERAMIC...........Ceramic
MT-PAPER.........Metallized Paper
POLYESTER......Polyester
MT-POLYEST.....Metallized Polyester
POLYPRO.......... Polypropylene
MT-POLYPRO....Metallized Polypropylene
COMPO FILM.....Composite film
MT-COMPO........Metallized Composite
STYRENE...........Styrene
TA-SOLID...........Tantalum Solid
AL-SOLID........... Aluminium Solid
ELECT................Electrolytic
NP-ELECT..........Non-polarised Electrolytic
OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT.......... Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W
Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M: ±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON........... Carbon
MT-FILM............ Metal Film
OXIDE-MT......... Oxide Metal Film
SOLID................ Composition
MT-GLAZE.........Metal Glaze
WIRE WOUND...Wire Wound
CERAMIC RES.. Ceramic
FUSIBLE RES....Fusible
NOTES:
