Sanyo LCD-32XH3 - Mechanical Disassembly Guide; Mechanical Disassembly Diagram

Mechanical Disassembly
-26-
[ Disassembly Diagram ]
Cabinet Front
Cover Stand Back
Cabinet Back Bottom
Button Unit
Top Cover
Cabinet Back
Dec. Stand
Stand Base
Rubber Pad
Stand Rotation Cover
SANYO Badge
Dec.
RC
Dec. Front Left
Dec. Front Right
ASSY, PWB, LED
LCD Module
ASSY, PWB, POWER
ASSY, PWB, MAIN
Panel Holder
ASSY
Speaker
Speaker Holder
Ter mi nal Base
Stand Bottom Plate
ASSY, PWB, KEY
