AC Power
Connect one end of the mains lead to the AC
INPUT ~ socket and the other end to an AC outlet.
Note:
- The installed batteries are automati-
cally disconnected when the mains lead is
connected to the unit.
- The FUNCTION switch is mounted on
the secondary side. The unit is not discon-
nected from mains, even switched off.
Battery power
Installing batteries
Install eight “D/HP2/R20” batteries (not sup-
plied) as shown in Fig. 2.
Caution on batteries
To prevent battery electrolyte leakage, which may
result in injury and damage to the unit or other
objects, observe the following precautions:
1. All batteries must be installed with the prop-
er polarity (see diagram on the back of the
unit).
2. Do not mix new with old or used batteries.
3. Only use batteries of the same type and
brand.
4. Remove the batteries when they are not to be
used for a long period time.
5. When the batteries have become discharged,
they must be disposed of in a safe manner
which complies with all applicable laws.
Adjusting the volume
Turn the VOLUME control.
Bass expander button
Press the BASSXPANDER button to Z ON to
enhance the bass sound.
Headphones
Connect stereo headphones (not supplied) to the
PHONES socket for monitoring or for private
listening. The speakers are automatically
disconnected when headphones are connected.
POWER SUPPLY GENERAL OPERATION
