Sanyo MDF-U2086S - MDF-U3086 S Specifications

33
SPECIFICATIONS
Name Ultra-low Temperature Freezer
Model MDF-U3086S
External dimensions W800 x D832 x H1810 (mm)
Internal dimensions W520 x D517 x H1120 (mm)
Effective capacity 301 L
Exterior Acrylic finish baked on galvanized steel
Interior Acrylic finish baked on galvanized steel
Door Acrylic finish baked on galvanized steel
Insulation Rigid polyurethane foamed-in place (CFC-FREE)
Compressor Hermetic type, High stage side; 400W, Low stage side; 600W
Condenser High stage side; fin and tube type, Low stage side; shell and tube type
Evaporator Tube on sheet type
Refrigerant High stage side; R-407D, Low stage side; R-508 (TP5R3)
Temperature control Microprocessor control system, 1
o
C graduation
Temperature display Digital display (+50
o
C to -100
o
C)
Sensor
Platinum resistance (PT 100Ω)
Alarm Buzzer & lamp, (filter alarm: lamp only), Remote alarm contact
Battery For power failure alarm; Nickel-cadmium battery, 6VDC, 270mAh
Shelf 6 shelves
Caster 4 casters.
Accessories 1 set of key, 2 rubber caps, 1 scraper, 24 shelf retainers
Weight 273 kg
Note: Design or specifications will be subject to change without notice.
The battery for power failure alarm is an article for consumption. It is recommended that the battery will
be replaced about every 3 years. Contact Sanyo sales agency at the time of replacement of the battery
for recycling.
PERFORMANCE
Model MDF-U3086S
Cooling performance Center part of freezing room; -86
o
C(ambient temperature; 30
o
C, no load)
Temperature control range -20
o
C to -90
o
C
Rated voltage AC 110 V AC 115 V AC 220 V AC 220 V AC 230 V AC 240 V
Rated frequency 60 Hz 60 Hz 60 Hz 50 Hz 50 Hz 50 Hz
Rated power consumption 826 W 826 W 785 W 826 W 785 W 785 W
Noise level 52 dB (A scale)
Maximum pressure 1726 kPa
Note :The unit with CE mark complies with EC directives 89/336/EEC, 93/68/EEC and 73/23/EEC.
