4
WM– 700703
Outdoor Unit: C1211 / CL1211
4 × 15/32 dia. hole
Air intake
Air discharge
23-15/16 2-3/8
29-17/32
Air
intake
Check port
2-1/4
1-3/16 9-27/32
20-7/8
21/32
3-23/32 2-3/8
1/4" narrow tubing
service valve
1/2" wide tubing
service valve
10-23/32
11-7/8
92-168S/M(Basic)00.12.1310:38AMページ4
