2-3.
Other Component Specifications
5 kohm
(at 25
°
C)
Model
Resistance
PTN-41G-S6Z
< Thermistor (Room sensor) >
AC277V 30A
Model
Rating
EL200/240A1-F (M)
15 kohm
(at 0
°
C)
5.4 kohm
(at 25
°
C)
Model
Resistance
PB2M-41E-S16-1
< Thermistor (Coil sensor) >
Indoor Unit
SAP-K77RAX
SAP-K97RAX
SAP-K127RAX
< Power Relay >
Outdoor Unit
SAP-C77RAX
SAP-C97RAX
SAP-C127RAX
15
14
16
Table of Contents
Table of Contents
3
Default Chapter
2
Special Precautions
2
1 Operating Range
5
2 Specifications
6
Unit Specifications
6
Major Component Specifications
9
Outdoor Unit
12
Other Component Specifications
15
3 Dimensional Data
16
4 Refrigerant Flow Diagram
19
5 Performance Data
20
Performance Charts
20
Air Throw Distance Charts
23
Cooling Capacity
26
6 Electrical Data
29
Electrical Characteristics
29
Electric Wiring Diagrams
30
7 Installation Instructions
32
Installation Site Selection
32
Recommended Wire Length and Diameter
34
Remote Control Unit Installation Position
35
How to Test Run the Air Conditioner
36
Removing and Installing the Grille
37
Address Setting of the Remote Control Unit
38
8 Functions
39
Room Temperature Control
39
Dry Operation (Dehumidification)
40
Freeze Prevention (Cooling and Dry)
41
Automatic Fan Speed (Cooling and Dry)
42
9 Troubleshooting
43
Check before and after Troubleshooting
43
Air Conditioner Does Not Operate
44
Some Part of Air Conditioner Does Not Operate
48
Only Compressor Does Not Run
49
Air Conditioner Operates, but Abnormalities Are Observed
50
10 Checking Electrical Components
51
Measurement of Insulation Resistance
51
Checking Continuity of Fuse on PCB Ass'y
52
Checking Motor Capacitor
52
Appendix Instruction Manual
53
Appendix
53
Instruction Manual
53
Features
54
Alert Symbols
55
Electrical Requirements
55
Installation Location
55
Product Information
55
Safety Instructions
55
Names of Parts
56
Remote Control Unit (Display)
57
Remote Control Unit
58
Using the Remote Control Unit
60
Operation with the Remote Control Unit
61
Operation
61
Adjusting the Fan Speed
61
Fan Only
61
ECONOMY Mode
62
Special Remarks
62
Using the 12-Hour on and off Timer
63
Tips for Energy Saving
64
Using the 1-Hour off Timer
64
Adjusting the Airflow Direction
65
Operation Without the Remote Control Unit
65
Care and Cleaning
66
Operating Range
67
Troubleshooting
67
