EVAPORATOR CONDENSER
ENT. TEMP. °C OUTDOOR AMBIENT TEMP. °C
W.B. D.B. 20 25 30 35 40 43
TC 2.57 2.46 2.35 2.23 2.10 1.93
CM 0.60 0.65 0.69 0.75 0.82 0.89
21 SHC 1.73 1.67 1.62 1.56 1.49 1.41
15 23 SHC 1.94 1.88 1.83 1.77 1.70 1.62
25 SHC 2.15 2.09 2.04 1.98 1.91 1.83
27 SHC 2.36 2.30 2.25 2.19 2.10 1.93
29 SHC 2.57 2.46 2.35 2.23 2.10 1.93
31 SHC 2.57 2.46 2.35 2.23 2.10 1.93
TC 2.76 2.64 2.52 2.40 2.25 2.07
CM 0.62 0.67 0.71 0.77 0.84 0.91
21 SHC 1.52 1.46 1.40 1.35 1.28 1.20
17 23 SHC 1.73 1.67 1.61 1.56 1.49 1.41
25 SHC 1.94 1.88 1.82 1.77 1.70 1.62
27 SHC 2.15 2.09 2.03 1.97 1.91 1.83
29 SHC 2.36 2.30 2.24 2.18 2.12 2.04
31 SHC 2.57 2.51 2.45 2.39 2.25 2.07
TC 2.93 2.81 2.68 # 2.55 2.40 2.21
CM 0.64 0.69 0.74 0.79 0.87 0.94
21 SHC 1.29 1.23 1.18 1.12 1.05 0.97
19 23 SHC 1.50 1.44 1.39 1.33 1.26 1.18
25 SHC 1.71 1.65 1.60 1.54 1.47 1.39
27 SHC 1.92 1.86 1.81 1.75 1.68 1.60
29 SHC 2.13 2.07 2.01 1.96 1.89 1.81
31 SHC 2.34 2.28 2.22 2.17 2.10 2.02
TC 3.11 2.97 2.84 2.70 2.54 2.34
CM 0.65 0.71 0.76 0.81 0.89 0.97
23 SHC 1.27 1.21 1.16 1.10 1.04 0.96
21 25 SHC 1.48 1.42 1.37 1.31 1.25 1.17
27 SHC 1.69 1.63 1.58 1.52 1.46 1.38
29 SHC 1.90 1.84 1.79 1.73 1.67 1.59
31 SHC 2.11 2.05 2.00 1.94 1.88 1.80
TC 3.30 3.16 3.01 2.84 2.66 2.47
CM 0.67 0.73 0.78 0.83 0.91 0.99
23 25 SHC 1.24 1.18 1.12 1.06 1.00 0.93
27 SHC 1.45 1.39 1.33 1.27 1.20 1.14
29 SHC 1.66 1.60 1.54 1.48 1.41 1.35
31 SHC 1.87 1.81 1.75 1.69 1.62 1.56
TC : Total Cooling Capacity (kW)
SHC : Sensible Heat Capacity (kW)
CM : Compressor Input (kW)
Rating conditions (#Mark) are
Outdoor Ambient Temp. 35°C D.B.
Indoor Unit Entering Air Temp. 27°C D.B. / 19°C W.B.
