Construction
E - 9
Indoor/outdoor
operation cable type
( size 0.5mm
2
- 2.0mm
2
)
CVV (JIS C3401)
Vinyl insulated vinyl sheath cable
for control
VCTF (JIS C3306) Vinyl cabtire round cord
VVR (JIS C3342)
Vinyl insulated vinyl sheath round
cable
MVVS or CPEVS Shield cable
(1) Cable size and fitting capacity
● Cable capacity(use 600V vinyl cable, IV cable as standard.
Supply on site)
● The value within ( ) for minimum cable size is the Maximum
length.
● For remote control cable, use the separately sold item. (for
exposed type)
1Multi-type indoor unit
Individual indoor power supply system
1) Embedded in the ceiling high static pressure type, without
direct expansion coil air processing unit.
Unit part
Indoor unit side (indivisual)
Embedded in the ceiling without direct expansion coil air processing unit
Type number 22 - 45 type 56 type 71 type 80, 90 type 112, 140 type 160 type
Switch ca
p
acit
y
(
A
)
30 30 30 30 30 30
Fuse ca
p
acit
y
(
A
)
15 15 15 15 15 15
Ca
p
acit
y
(
A
)
20 20 20 20 20 20
Leakage current(mA) 30 30 30 30 30 30
Earth leakage breaker
Operating time(sec) 0.1 or less 0.1 or less 0.1 or less 0.1 or less 0.1 or less 0.1 or less
Minimum cable size 2mm
2
(197) 2mm
2
(174) 2mm
2
(146) 2mm
2
(115) 2mm
2
(83) 2mm
2
(104)
U
p
to 25m len
g
th 2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
U
p
to 50m len
g
th 2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
U
p
to 75m len
g
th 2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
Electrical power cable
(metal pipe, vinyl
chloride pipe)
Voltage drop standard
2%
Up to 100m length 2mm
2
2mm
2
2mm
2
2mm
2
3.5mm
2
2mm
2
Earth cable size 2mm
2
Indoor
/
outdoor o
p
eration cable 0.5mm
2
- 2mm
2
(
total len
g
th u
p
to 1000ｍ
)
Remote control cable size 0.5mm
2
- 2mm
2
(
total len
g
th u
p
to 500ｍ
)
The value within ( ) for the minimum cable size is the maximum length.
For remote control cable, use separately sold item (exposed type)
2) Embedded in the ceiling high static pressure type and air processing unit with direct expansion coil.
Indoor unit ( separate)
Unit part
Embedded in the ceiling Direct expansion coil air processing unit
T
yp
e numbe
r
71 t
yp
e 90, 112 t
yp
e 140 t
yp
e 50 t
yp
e 75 t
yp
e 100 t
yp
e
Switch ca
p
acit
y
(
A
)
30 30 30 30 30 30
Fuse ca
p
acit
y
(
A
)
15 15 15 15 15 15
Ca
p
acit
y
(
A
)
20 20 20 20 20 20
Leaka
g
e curren
t
(
mA
)
30 30 30 30 30 30
Earth leakage breaker
Operation time(sec) 0.1 or less 0.1 or less 0.1 or less 0.1 or less 0.1 or less 0.1 or less
Cable minimum size 2mm
2
(65) 2mm
2
(55) 2mm
2
(44) 2mm
2
(47) 2mm
2
(39) 2mm
2
(34)
U
p
to 25m len
g
th 2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
2mm
2
U
p
to 50m len
g
th 2mm
2
2mm
2
3.5mm
2
3.5mm
2
3.5mm
2
3.5mm
2
U
p
to 75m len
g
th 3.5mm
2
3.5mm
2
5.5mm
2
5.5mm
2
5.5mm
2
5.5mm
2
Electrical power cable
(metal pipe, vinyl
chloride pipe)
Voltage drop standard
U
p
to 100m len
g
th 3.5mm
2
5.5mm
2
5.5mm
2
5.5mm
2
5.5mm
2
8mm
2
Earth cable size 2mm
2
Indoor
/
outdoor o
p
eration cable 0.5mm
2
- 2mm
2
（total len
g
th u
p
to 1000ｍ）
Remote control cable size 0.5mm
2
- 2mm
2
（total len
g
th u
p
to 500ｍ）
The value inside ( ) for cable minimum size is the maximum length (m).
For remote control cable, use the separately sold item (exposed type)
3. Points regarding electrical construction (indoor unit)
