SM830052
I-19
ECO MULTI SYSTEM Unit Specifications
1
2-1. Specifications
Unit specifications (A)
2. 4-Way Air Discharge Semi-concealed Type
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °C DB / 6 °C WB
MODEL No. Indoor Unit SPW-X123GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase – 50Hz
PERFORMANCE Cooling Heating
Capacity kW 3.6 4.2
BTU / h 12,000 14,000
Air circulation (Hi / Me / Lo) m
3
/h 900 / 780 / 660
Moisture removal (High) Liters/h 1.5 —
ELECTRICAL RATINGS
Voltage rating V 220 - 230 - 240
Available voltage range V 198 – 264
Running amperes A 0.60 - 0.62 - 0.63 0.37 - 0.40 - 0.42
Power input W 130 - 140 - 150 80 - 90 - 100
Power factor % 98 - 98 - 99 98 - 98 - 99
Fan motor locked rotor amperes A 1 - 1 - 1
FEATURES
Controls / Temperature control Microprocessor / I.C. thermostat
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds 3 and Automatic control
Air filter Washable, easy access
Refrigerant control Electronic refrigerant control valve
Operation sound (Hi / Me / Lo) dB-A 37 / 35 / 30
Refrigerant tubing connections Flare type
Refrigerant tube diameter Narrow tube mm (in.) 9.52 (3 / 8)
Wide tube mm (in.) 12.7 (1 / 2)
Drain connection 25 A, OD32 mm
Drain pump Max. head 25 cm above drain connection
Remote Controller Optional (RCS-SH80TG)
Refrigerant tubing kit / Accessories Optional / —
DIMENSIONS & WEIGHT (include ceiling panel) Unit dimensions Package dimensions
Dimensions Height mm (in.) 328 ( 12 - 29 / 32) 410 (16 - 3 / 8)
Width mm (in.) 860 ( 33 - 7 / 8) 988 ( 38 - 7 / 8)
Depth mm (in.) 860 ( 33 - 7 / 8) 988 ( 38 -7 /8)
Net weight kg (lbs.) 29 ( 64 )
Shipping weight kg (lbs.) 46 ( 101 )
Shipping volume m
3
(cu. ft) 0.400 ( 14.1 )
To Next Page
