- 4 -
The following parts can deteriorate and become worn as a
result of repeated pan and tilt operations, and this can result
in problems occurring such as vibration while pan/tilt
operations are carried out, position errors during sequencing
operation, and failure to operate. These parts should be
replaced periodically after roughly either 1.2 million operations
or 2 years.
MOTOR,FAN should be replaced periodically after roughly 3.5
years.
1.MAINTENANCE
1.Maintenance Table
When replacing parts, check the PAN COUNT and TILT
COUNT values in MTR-COUNT, and at the same time be sure
to clear the counter values.
1.Use the system controller to display the camera menu on
the monitor.
2.Use the SELECT button to move the cursor to “OPTION”.
Move the SELECT button to [Right] -> [Right] -> [Left] ->
[Left] in that order and then press the SET button to
display the SERVICE MENU screen.
The number of pan motor and tilt motor operations will be
displayed in MTR-COUNT, so check the counter values.
3.When replacing parts, clear the counter values.
Use the SELECT button to move the cursor to the PAN
counter value in “MTR-COUNT”, and then operate the
SELECT button in the order [Right] -> [Right] -> [Left] ->
[Left] and press the SET button to clear the PAN/TILT
counter values.
SERVICE MENU
CAMERA VER
MAIN VER
SSP VER
MTR-COUNT PAN
TILT
0 0
0 0
INITIAL OFF
MENU END
BACKUP SAVE
MTR-COUNT is used as a guide for checking the number of
pan/tilt motor operations.
One starting and stopping of the motor as a result of a pan or
tilt operation is counted as one operation, and each time 100
such operations occur, the value in the 100 column is
incremented by one. (The numbers in the 0 and 10 column
are fixed at “0”.)
2. Checking and clearing the counter values for PAN
COUNT and TILT COUNT
PARTS NO.
645 091 0104
645 090 3861
645 090 3878
645 088 7086
DESCRIPTION
ASSY,TERMINAL,SLIP RING
ASSY,MOTOR STEPPING PAN
ASSY,MOTOR STEPPING TIL
LENS(ASSY),X35
PARTS NO.
645 091 5192
DESCRIPTION
MOTOR,FAN DC 0.55W
To Next Page
