— 12 —
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
C5738 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5739 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5741 CK1A105KLZBNG CERAMIC 1U K 10V
C5742 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5743 CK1A105KLZBNG CERAMIC 1U K 10V
C5744 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5745 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5746 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5747 CK1A105KLZBNG CERAMIC 1U K 10V
C5748 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5751 CE1V470MZVALC ELECT 47U M 35V
C5755 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5756 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5761 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5762 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5763 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5764 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5765 CK1A105KLZBNG CERAMIC 1U K 10V
C5766 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5767 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5802 CC1H680JLZCNG CERAMIC 68P J 50V
C5803 CC1H680JLZCNG CERAMIC 68P J 50V
C5804 CC1H680JLZCNG CERAMIC 68P J 50V
C5806 CC1H270JLZCNG CERAMIC 27P J 50V
C5807 CC1H270JLZCNG CERAMIC 27P J 50V
C5808 CC1H270JLZCNG CERAMIC 27P J 50V
C5810 CC1H5R0CLZCNG CERAMIC 5P C 50V
C5811 CC1H5R0CLZCNG CERAMIC 5P C 50V
C5812 CC1H5R0CLZCNG CERAMIC 5P C 50V
C5814 CC1H120JLZCNG CERAMIC 12P J 50V
C5815 CC1H120JLZCNG CERAMIC 12P J 50V
C5816 CC1H120JLZCNG CERAMIC 12P J 50V
C5818 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5819 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5820 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5821 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5822 CEXLB1H100VDJ ELECT 10U M 50V
C5823 CEXLB1H100VDJ ELECT 10U M 50V
C5902 CK1A105KLZBNG CERAMIC 1U K 10V
C5904 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5905 CE1H100MZVALC ELECT 10U M 50V
C6052 CK1A105KLZBNG CERAMIC 1U K 10V
C6053 CK1A105KLZBNG CERAMIC 1U K 10V
C6054 CE0J221MZVALC ELECT 220U M 6.3V
C6055 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6060 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6061 CK1A105KLZBNG CERAMIC 1U K 10V
C6065 CK1A105KLZBNG CERAMIC 1U K 10V
C6066 CE0J221MZVALC ELECT 220U M 6.3V
C6072 CK1A105KLZBNG CERAMIC 1U K 10V
C6073 CK1A105KLZBNG CERAMIC 1U K 10V
C6074 CE0J221MZVALC ELECT 220U M 6.3V
C6075 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6101 CK1H102KLZBNG CERAMIC 1000P K 50V
C6102 CK1H102KLZBNG CERAMIC 1000P K 50V
C6106 CC1H220JLZCNG CERAMIC 22P J 50V
C6107 CC1H220JLZCNG CERAMIC 22P J 50V
C6110 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6111 CEXLB0J102VDJ ELECT 1000U M 6.3V
C6112 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6118 CK1H103KLZBNG CERAMIC 0.01U K 50V
C6119 CK1H103KLZBNG CERAMIC 0.01U K 50V
C6121 CC1H120JLZCNG CERAMIC 12P J 50V
C6122 RGFR000ZTCANL MT-GLAZE 0 ZA 1/10W
C6123 CC1H120JLZCNG CERAMIC 12P J 50V
C6124 RGFR000ZTCANL MT-GLAZE 0 ZA 1/10W
C6125 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6201 CC1H471JLZCNG CERAMIC 470P J 50V
C6202 CC1H680JLZCNG CERAMIC 68P J 50V
C6203 CC1H680JLZCNG CERAMIC 68P J 50V
C6204 CC1H680JLZCNG CERAMIC 68P J 50V
C6205 CC1H471JLZCNG CERAMIC 470P J 50V
C6206 CC1H680JLZCNG CERAMIC 68P J 50V
C6207 CEXLB1H100VDJ ELECT 10U M 50V
C6208 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6209 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6210 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6212 CEXLB1H100VDJ ELECT 10U M 50V
C6270 CE1H100MZVALC ELECT 10U M 50V
C6271 CEXLB1H100VDJ ELECT 10U M 50V
C6272 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6273 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6274 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6275 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6276 CEXLB1H100VDJ ELECT 10U M 50V
C6277 CEXLB1H100VDJ ELECT 10U M 50V
C6278 CK1A105KLZBNG CERAMIC 1U K 10V
C6279 CK1A105KLZBNG CERAMIC 1U K 10V
C6354 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6361 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C6362 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6363 CEXLB1H100VDJ ELECT 10U M 50V
C6364 CEXLB1C101VDJ ELECT 100U M 16V
C6365 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6409 CE0J222MZVALC ELECT 2200U M 6.3V
C6410 CE0J222MZVALC ELECT 2200U M 6.3V
C6501 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6502 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6503 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6504 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6505 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6509 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6510 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6511 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6512 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6513 CK1H102KLZBNG CERAMIC 1000P K 50V
C6514 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6515 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
