Sanyo Vizon DP37647 User Manual

— 11 —
Schematic
Location
Part No.
Description
C5608 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5609 CE0J221MZVALC ELECT 220U M 6.3V
C5611 CC1H470JLZCNG CERAMIC 47P J 50V
C5612 CC1H470JLZCNG CERAMIC 47P J 50V
C5614 CC1H470JLZCNG CERAMIC 47P J 50V
C5615 CC1H470JLZCNG CERAMIC 47P J 50V
C5617 CC1H470JLZCNG CERAMIC 47P J 50V
C5618 CC1H470JLZCNG CERAMIC 47P J 50V
C5621 CC1H470JLZCNG CERAMIC 47P J 50V
C5622 CC1H470JLZCNG CERAMIC 47P J 50V
C5624 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5625 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5627 CC1H470JLZCNG CERAMIC 47P J 50V
C5628 CC1H470JLZCNG CERAMIC 47P J 50V
C5629 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5631 CK1A105KLZBNG CERAMIC 1U K 10V
C5632 CK1A105KLZBNG CERAMIC 1U K 10V
C5633 CK1A105KLZBNG CERAMIC 1U K 10V
C5634 CK1A105KLZBNG CERAMIC 1U K 10V
C5635 CK1A105KLZBNG CERAMIC 1U K 10V
C5636 CK1A105KLZBNG CERAMIC 1U K 10V
C5637 CK1A105KLZBNG CERAMIC 1U K 10V
C5638 CK1A105KLZBNG CERAMIC 1U K 10V
C5639 CK1A105KLZBNG CERAMIC 1U K 10V
C5641 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5642 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5643 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5644 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5645 CK1A105KLZBNG CERAMIC 1U K 10V
C5646 CK1A105KLZBNG CERAMIC 1U K 10V
C5647 CK1A105KLZBNG CERAMIC 1U K 10V
C5651 CK1A105KLZBNG CERAMIC 1U K 10V
C5652 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5653 CK1A105KLZBNG CERAMIC 1U K 10V
C5654 CC1H470JLZCNG CERAMIC 47P J 50V
C5655 CC1H470JLZCNG CERAMIC 47P J 50V
C5656 CK1A105KLZBNG CERAMIC 1U K 10V
C5657 CK1A105KLZBNG CERAMIC 1U K 10V
C5661 CK1A105KLZBNG CERAMIC 1U K 10V
C5662 CK1A105KLZBNG CERAMIC 1U K 10V
C5663 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5664 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5665 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5666 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5667 CK1A105KLZBNG CERAMIC 1U K 10V
C5668 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5669 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5671 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5672 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5673 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5674 CK1A105KLZBNG CERAMIC 1U K 10V
C5675 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5676 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5677 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5678 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5679 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5681 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5682 CK1A105KLZBNG CERAMIC 1U K 10V
C5683 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5684 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5685 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5686 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5687 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5688 CK1A105KLZBNG CERAMIC 1U K 10V
C5689 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5695 CK1A105KLZBNG CERAMIC 1U K 10V
C5696 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5698 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5699 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5701 CE0J221MZVALC ELECT 220U M 6.3V
C5702 CK1A105KLZBNG CERAMIC 1U K 10V
C5703 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5704 CK1A105KLZBNG CERAMIC 1U K 10V
C5705 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5706 CK1A105KLZBNG CERAMIC 1U K 10V
C5707 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5708 CK1A105KLZBNG CERAMIC 1U K 10V
C5709 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5710 CC1H471JLZCNG CERAMIC 470P J 50V
C5711 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5712 CK1A105KLZBNG CERAMIC 1U K 10V
C5713 CK1A105KLZBNG CERAMIC 1U K 10V
C5714 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5715 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5716 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5717 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5718 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5719 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5720 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5721 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5722 CC1H471JLZCNG CERAMIC 470P J 50V
C5723 CK1A105KLZBNG CERAMIC 1U K 10V
C5724 CK1A105KLZBNG CERAMIC 1U K 10V
C5725 CK1A105KLZBNG CERAMIC 1U K 10V
C5726 CK1A105KLZBNG CERAMIC 1U K 10V
C5727 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5728 CK1A105KLZBNG CERAMIC 1U K 10V
C5729 CK1A105KLZBNG CERAMIC 1U K 10V
C5730 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5731 CK1A105KLZBNG CERAMIC 1U K 10V
C5732 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5733 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5734 CK1A105KLZBNG CERAMIC 1U K 10V
C5735 CK1A105KLZBNG CERAMIC 1U K 10V
C5736 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5737 CK1A105KLZBNG CERAMIC 1U K 10V
Schematic
Location
Part No.
Description
