— 10 —
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
C3202 CK1A105KLZBNG CERAMIC 1U K 10V
C3203 CK1A105KLZBNG CERAMIC 1U K 10V
C3204 CK1H223KLZBNG CERAMIC0.022U K 50V
C3205 CK1H222KLZBNG CERAMIC 2200P K 50V
C3206 CK1H104KLZBNG CERAMIC 0.1U K 50V
C3208 CK1A105KLZBNG CERAMIC 1U K 10V
C3209 CK1A105KLZBNG CERAMIC 1U K 10V
C3210 CK1A105KLZBNG CERAMIC 1U K 10V
C3211 CK1A105KLZBNG CERAMIC 1U K 10V
C3212 CK1A105KLZBNG CERAMIC 1U K 10V
C3213 CK1A105KLZBNG CERAMIC 1U K 10V
C3214 CK1A105KLZBNG CERAMIC 1U K 10V
C3215 CK1H222KLZBNG CERAMIC 2200P K 50V
C3216 CK1H104KLZBNG CERAMIC 0.1U K 50V
C3217 CK1A105KLZBNG CERAMIC 1U K 10V
C3218 CK1A474KLZBNG CERAMIC 0.47U K 10V
C3219 CK1A105KLZBNG CERAMIC 1U K 10V
C3220 CK1A105KLZBNG CERAMIC 1U K 10V
C3221 CK1A105KLZBNG CERAMIC 1U K 10V
C3222 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3223 CEXLB1C222VDJ ELECT 2200U M 16V
C5501 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5502 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5503 CC1H5R0CLZCNG CERAMIC 5P C 50V
C5504 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5505 CC1H5R0CLZCNG CERAMIC 5P C 50V
C5506 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5507 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5508 CE1V470MZVALC ELECT 47U M 35V
C5509 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5511 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5512 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5513 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5514 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5515 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5516 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5517 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5519 CK1A105KLZBNG CERAMIC 1U K 10V
C5522 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5523 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5524 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5525 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5526 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5527 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5528 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5529 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5531 CK1A105KLZBNG CERAMIC 1U K 10V
C5532 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5534 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5535 CK1A105KLZBNG CERAMIC 1U K 10V
C5536 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5537 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5538 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5539 CK1A105KLZBNG CERAMIC 1U K 10V
C5541 CK1A105KLZBNG CERAMIC 1U K 10V
C5543 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5544 CK1A105KLZBNG CERAMIC 1U K 10V
C5545 CK1A105KLZBNG CERAMIC 1U K 10V
C5546 CK1A105KLZBNG CERAMIC 1U K 10V
C5547 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5548 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5549 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5551 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5552 CK1H102KLZBNG CERAMIC 1000P K 50V
C5553 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5554 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5555 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5556 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5557 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5558 CK1H102KLZBNG CERAMIC 1000P K 50V
C5559 CE1V470MZVALC ELECT 47U M 35V
C5563 CK1A105KLZBNG CERAMIC 1U K 10V
C5564 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5565 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5566 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5567 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5568 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5569 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5571 CK1H102KLZBNG CERAMIC 1000P K 50V
C5573 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5574 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5575 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5576 CK1H102KLZBNG CERAMIC 1000P K 50V
C5577 CK1A105KLZBNG CERAMIC 1U K 10V
C5578 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5579 CK1A105KLZBNG CERAMIC 1U K 10V
C5581 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5582 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5583 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5584 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5585 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5586 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5587 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5588 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5589 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5591 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5592 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5593 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5594 CK1H223KLZBNG CERAMIC0.022U K 50V
C5596 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5597 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5598 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5599 CE1V470MZVALC ELECT 47U M 35V
C5601 CE0J221MZVALC ELECT 220U M 6.3V
C5602 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5603 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5605 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5606 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
