Sanyo Vizon DP37647 User Manual

— 9 —
Schematic
Location
Part No.
Description
CAPACITORS
C001 CPXLB1C100YAJ NP-ELECT 10U M 16V
C001 CPXLB1C100ZAJ NP-ELECT 10U M 16V
C002 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C006 CEXLB1H100VDJ ELECT 10U M 50V
C007 CEXLB1C101VDJ ELECT 100U M 16V
C008 CK1H102KLZBNG CERAMIC 1000P K 50V
C009 CK1H102KLZBNG CERAMIC 1000P K 50V
C013 CPXLB1C100YAJ NP-ELECT 10U M 16V
C013 CPXLB1C100ZAJ NP-ELECT 10U M 16V
C015 CEXLB1C222VDJ ELECT 2200U M 16V
C016 CEXLB1H100VDJ ELECT 10U M 50V
C017 CEXLB1H100VDJ ELECT 10U M 50V
C801 CK1A105KLZBNG CERAMIC 1U K 10V
C802 CK1H104KLZBNG CERAMIC 0.1U K 50V
C803 CEXLB1V470VDJ ELECT 47U M 35V
C804 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C805 CK1H103KLZBNG CERAMIC 0.01U K 50V
C807 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C809 CC1H220JLZCNG CERAMIC 22P J 50V
C810 CC1H220JLZCNG CERAMIC 22P J 50V
C811 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C812 CC1H470JLZCNG CERAMIC 47P J 50V
C813 CC1H470JLZCNG CERAMIC 47P J 50V
C814 CK1H103KLZBNG CERAMIC 0.01U K 50V
C816 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C818 CK1H222KLZBNG CERAMIC 2200P K 50V
C819 CEXLB0J221VDJ ELECT 220U M 6.3V
C821 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C822 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C823 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C824 CK1H103KLZBNG CERAMIC 0.01U K 50V
C825 CC1H470JLZCNG CERAMIC 47P J 50V
C1002 CEXLB1V470VDJ ELECT 47U M 35V
C1003 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
C1004 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
C1011 CEXLB1H100VDJ ELECT 10U M 50V
C1012 CEXLB1H100VDJ ELECT 10U M 50V
C1013 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
C1014 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
C1015 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
C1016 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
C1017 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
C1205 CEXLB1V470VDJ ELECT 47U M 35V
C1251 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1606 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1608 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1609 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1610 CEXLB1E102VDJ ELECT 1K U M 25V
C1611 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1612 CC1H221JLZCNG CERAMIC 220P J 50V
C1613 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1614 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1617 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1618 CK1H392KLZBNG CERAMIC 3900P K 50V
C1620 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1621 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1622 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1623 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1624 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1625 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1626 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1627 CE0J102MZVALC ELECT 1000U M 6.3V
C1628 CEXLB0J102VDJ ELECT 1000U M 6.3V
C1629 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1630 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1631 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1641 CE1E102MZVANC ELECT 1000U M 25V
C1642 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1647 CEXLB0J102VDJ ELECT 1000U M 6.3V
C1648 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1649 CK1A105KLZBNG CERAMIC 1U K 10V
C1650 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1655 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1656 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1657 CEXLB1E102VDJ ELECT 1K U M 25V
C1658 CK1H222KLZBNG CERAMIC 2200P K 50V
C1659 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1660 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1669 CEXLB1V471VDJ ELECT 470U M 35V
C1670 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1672 CEXLB1C101VDJ ELECT 100U M 16V
C1673 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1675 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1678 CEXLB1C101VDJ ELECT 100U M 16V
C1679 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1680 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1681 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1682 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1683 CEXLB1V471VDJ ELECT 470U M 35V
C1684 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1685 CEXLB1E102VDJ ELECT 1K U M 25V
C1686 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1687 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1689 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1690 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1693 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1694 CEXLB1V470VDJ ELECT 47U M 35V
C1803 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C1810 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1811 CEXLB1C101VDJ ELECT 100U M 16V
C1903 CEXLB1V470VDJ ELECT 47U M 35V
C1904 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1905 CC1H470JLZCNG CERAMIC 47P J 50V
C3200 CK1A105KLZBNG CERAMIC 1U K 10V
C3201 CK1A105KLZBNG CERAMIC 1U K 10V
Schematic
Location
Part No.
Description
