— 49 —
All Modes?
Yes
No
RF(TV) only
AV1 only
Check:
Line: A101 17pin - IC3403 2pin
Parts: Around
A101 (TU), IC3403 (Video Selector)
AV3 only
AV2 only
Check:
Line:
IC3403 1pin (CV), IC3403 3pin (Y)
Digital Module K1052 46pin (C)
Parts: Around
Digital Module, IC3403
Digital Module Input only
Check:
Parts: Digital Module (A/D Converter)
Check:
Parts: Around Digital Module
Check:
Line:
IC3403 2pin - Q3459 - Digital Module (CV/Y)
Parts: Around
IC3403, Q3459, Digital Module
Check:
RF(TV), AV1
AV2, AV3
Line:
Q2906 - Digital Module (Y)
Q2904 - Digital Module (U)
Q2902 - Digital Module (V)
Parts: Around
Q2906, Q2904, Q2902
Check:
Line:
Q2950 - Digital Module (Y)
Q2943 - Digital Module (U)
Q2942 - Digital Module (V)
Parts: Around
Q2950, Q2943, Q2942
Check:
Line:
Digital Module - IC2501 51pin (YP)
Digital Module - IC2501 52pin (UP)
Digital Module - IC2501 53pin (VP)
Digital Module - IC2501 18pin (2HS)
Digital Module - IC2501 23pin (VS)
IC2501 34pin - Q2503 - Q711 - IC701 3-8pin - CRT (R-Cathode)
IC2501 32pin - Q2502 - Q721 - IC701 5-6pin - CRT (G-Cathode)
IC2501 30pin - Q2501 - Q731 - IC701 1-10pin - CRT (B-Cathode)
IC701 9pin - Q774 - IC2501 27pin (IK)
IC2501 16/1/64/3/14pin - Power Deflection Circuit (H,V Drive, PCC, AFC)
Parts: Around
Digital Module, IC2501 (Video Processor), IC701 (CRT Drive), CRT,
Q2501, Q2502, Q2503, Q711,Q721, Q731, T402 (FBT, Screen VR)
Caption, OSD only
NO PICTURE
