Adjusting method:
1.Press the RESET key once (when using VJ8-01 03).
Press the RESET key and AID key simultaneously, and
then release the RESET key first (when using VJ8-0141 ).
2. Operate the CH-UP key or the CH-DOWN key to
designate EVR CH3.
3. Operate the DATA-CENT key, DATA-UP key and DATA-
DOWN key to set the [IRIS DET.] waveform level to 500
f 20 mvp-p.
4. Press the WRT key to store the adjusting data.
T
500 f 20 mVp-p
L
.-
6. AGC Level Adjustment
Meaauring point I
Meaauring Equipment
Condition
Test pin array
Oscilloscope
CAMERA EE
J9001 @
[AGC. DET]
Subject
J9001 @ [GND] Gray scale (standard picture frame)
(Place LBA8s in front of lens)
ADJ. Location
ADJ. Value
I EVR CH4
I 500 f 20 mVp-p I
Preparation:
● Short pin @ and pin @ of J9001.
Adjusting method:
1.Press the RESET key once (when using VJ8-01 03).
Press the RESET key and AID key simultaneously, and
then release the RESET key first (when using VJ8-0141 ).
2. Operate the CH-UP key or the CH-DOWN key to
designate EVR CH4.
3. Operate the DATA-CENT key, DATA-UP key and DATA-
DOWN key to set the [AGC.DET] waveform level to 500
* 20 mvp-p.
4. Press the WRT key to store the adjusting data.
T
500 f 20 mVp-p
L
7.
Y Level Adjustment
Meaauring Point
Meaauring Equipment
Condition
TP141 Oscilloscope
CAMERA EE
(video output)
TP143 (GND)
~
Gray scale (standard picture frame)
ADJ. Location
ADJ. Value
EVR CH5
S: V=300:(740f 20)
Preparation:
● Short pin @ and pin @ of J9001.
Adjusting method:
1.Press the RESET key once (when using VJ8-01 03).
Press the RESET key and AID key simultaneously, and
then release the RESET key first (when using VJ8-0141 ).
2. Operate the CH-UP key or the CH-DOWN key to
designate EVR CH5.
3. Operate the DATA-CENT key, DATA-UP key and DATA-
DOWN key to set the S : V ratio to 300: (740 f 20).
4. Press the WRT key to store the adjusting data.
T
v (740 f 20)
-J-
S (300)
T
8. Chroma Balance Adjustment
Meaauring Point
Meaauring Equipment
Condition
TP141 Vectorscope
CAMERA EE
(video output)
I
TP143 (GND)
Subject
Color bar (standard picture frame)
ADJ. Location
ADJ. Value
EVR CH6
l———————
Preparation:
● Short pin @ and pin @ of J9001.
Adjusting method:
1.Adjust the gain and phase of the vectorscope so that the
burst becomes 75Y0.
2. Press the RESET key once (when using VJ8-01 03).
Press the RESET key and AiD key simultaneously, and
then release the RESET key first (when using VJ8-0141 ).
3. Operate the CH-UP key or the CH-DOWN key to
designate EVR CH6.
4. Operate the DATA-CENT key, DATA-UP key and DATA-
DOWN key to focus the luminance points which indicates
color vectors respectively.
● Adjust especially paying attention to the red vector.
5. Press the WRT key to store the adjusting data.
