1. Specifications
1-3 Other Component Specifications
(B) Outdoor Unit
MODEL No. CH2432
Compressor Motor Magnetic Contactor FMCA - 1UL
Coil rated 240 VAC, 60 Hz
Coil resistance (at 77 °F) Ω 580 ± 15 %
Contact rated (Main) 230 VAC, 20 A
Contact rated (Auxiliary) 230 VAC, 3 A
Power Relay HH62S
Coil rated 240 VAC, 60 Hz
Coil resistance (at 77 °F) kΩ 17.2
Contact rated 220 VAC, 5 A
Power Transformer ATR - I65C
Rated
Primary 220 VAC, 60 Hz
Secondary 14 V, 0.4 A
Capacity 5.6 VA
Coil resistance (at 73 °F ) Ω WHT – WHT : 395.5 , BRN – BRN : 2.19
Thermal cut off temperature °F266
Thermistor (Coil sensor) : TH6, 7 PBC - 41E - S4 , PBC - 41E - S26
Coil resistance kΩ 14 °F : 23.7 , 50 °F : 9.7
23 °F : 18.8 , 68 °F : 6.5
32 °F : 15.0 , 86 °F : 4.4
41 °F : 12.1 , 104 °F : 3.1
113 °F : 2.6
Thermistor (Comp. discharge gas sensor) : TH8 PTC - 51H - S1
Coil resistance kΩ 140 °F : 13.8 , 194 °F : 5.1
158 °F : 9.7 , 212 °F : 3.8
167 °F : 8.2 , 230 °F : 2.8
176 °F : 7.0 , 248 °F : 2.2
185 °F : 5.9 , 266 °F : 1.7
Solenoid control valve or coil
Solenoid control valve V 389100
Solenoid coil LB 59005
Thermistor (PTC) TDK – 101YV
Rated
Max. voltage 400 VAC
Max. ampere 11.5 A
Resistance (at 77 °F) Ω 100 %
DATA SUBJECT TO CHANGE WITHOUT NOTICE
+ 30
– 20
