User Manual & Datasheet V 2.3
17 Product Selection Order Code
Product
VITAL : Compact Vibrating Fork Type Level Limit Switch for free flowing solids, granules and powders
Type
I : Integral (sensor in same unit)
Housing
SCUTE : Pressure Die Cast Aluminium weather proof (Rating IP-68) SCUTE
FP2C : Cast Aluminium weather & flame proof powder coated suitable for gas group IIC
Indication (Optional)
WL : External LED Indication (Only with “SCUTE”)
Probe Housing Cable Entry
PCPG13 : PG 13.5, Polyamide
PCB5D : 1/2” BSP, DC Gland, Brass
PCN5D : 1/2” NPT, DC Gland, Brass
Output
D : 2NO, 2NC DPDT Relay Output (rated at 6 A, 230 V AC for non-inductive load)
SPN : SPDT Relay output 1NO, 1NC (Relay rated at 6 A, 230 V AC for non-inductive load) and PNP output (only for supply voltage
18V to 35V DC)
Power Supply
U : Universal (18 to 55V DC) and (90 to 265V at 50Hz AC)
Switching (Depends on “Vibrating Fork”)
FS : Time Delay (Adjustable from 0.5 to 20 seconds for probe covered or uncovered) (Only with “VF105S”, “VF130”)
NS : Normal Time Delay (Adjustable from 2 to 20 seconds for probe covered or uncovered)
Mounting
MB15MS : Screwed Thread, BSP 1-1/2”, MS Plated
MB15S4 : Screwed Thread, BSP 1-1/2”, SS 304
MB15S6 : Screwed Thread, BSP 1-1/2”, SS 316
MN15MS : Screwed Thread, NPT 1-1/2”, MS Plated
MN15S4 : Screwed Thread, NPT 1-1/2”, SS 304
MN15S6 : Screwed Thread, NPT 1-1/2”, SS 316
FA20MS : 2” ANSI Flange, MS Plated
FA20S4 : 2” ANSI Flange, SS 304
FA20S6 : 2” ANSI Flange, SS 316
FA25MS : 2-1/2” ANSI Flange, MS Plated
FA25S4 : 2-1/2” ANSI Flange, SS 304
FA25S6 : 2-1/2” ANSI Flange, SS 316
F20MS : 2” ASA Flange, 10mm thickness, MS Plated
F20S4 : 2” ASA Flange, 10mm thickness, SS 304
F20S6 : 2” ASA Flange, 10mm thickness, SS 316
F25MS : 2-1/2” ASA Flange, 10mm thickness, MS Plated
F25S4 : 2-1/2” ASA Flange, 10mm thickness, SS 304
F25S6 : 2-1/2” ASA Flange, 10mm thickness, SS 316
F20B15MS : 2” ASA Slip-ON Flange with 1-1/2” BSP Thread, 10mm thickness, MS Plated
Sapcon Instruments Pvt.Ltd.
R
12
