Sapcon Vital - Electrical Specifications; Application Specifications

User Manual & Datasheet V 2.3
5 Electrical Specifications
Please refer to Table 1 for Electrical Specifications.
PARAMETER VALUE
Input Power Supply 18 - 55V DC and 90 - 265V AC at 50Hz on same terminal
Output
• Relay DPDT
• Relay SPDT, PNP
Power Consumption
• 1.5W (SPDT, PNP) at 24 V
• 2.2W (DPDT) at 24 V
Switching Single-point level switching
Switching Indication Bi-Color LED on the electronics insert
• Green - Normal
• Red - Alarm
External LED between the cable glands(with option WL)
• Blue - Normal
• Red - Alarm
Fail-safe Field Selectable
• Open - Fail-safe High (For High Level)
• Close - Fail-safe Low (For Low Level)
Time Delay Settings 1 - 25 seconds (For both, Covered and Uncovered Delays)
Operating Temperature
• Ambient Temperature: 0
◦
C to 65
◦
C
• Process Temperature: 0
◦
C to 100
◦
C with option HT
Relay Rating 6 Amp at 230 VAC
Table 1: Electrical Specifications
6 Application Specifications
Please refer to Table 2 for Application Specifications.
PARAMETER VALUE
Sensitivity
• Dense Media/Build Up - 1
• Ligthter Media - 5
Density of media (min) 0.7 gm/cm
3
Grain Size A maximum of 12mm
Response Time with ’NS’ option
• Cover Delay : 1-2 second
• Uncover Delay : 1-3 seconds
Response Time with ’FS’ option
• Cover Delay : 1 second
• Uncover Delay : 0.8 seconds
Table 2: Application Specifications
