Double Mount Installation - Square Clock - Battery Powered
8) Release the mounting piece from the back of
each housing by sliding it away from the center of
the housing, then pulling it back and away from
the housing. You will not need the mounting pieces
later; either store them or throw them away at your
discretion. DO NOT THROW AWAY
THE HOUSINGS.
9) Attach both housings to the pole using four black
8-32x7/16 screws and four internal-tooth washers
on each side.
10) Attach the housings to each other using the four black M3.5-1.0x10 screws, two on each housing.
1
2
Mounting
piece
Housing
To Next Page
