2
The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
P. (+1) 215.322.6063
F. (+1) 215.322.8498
www.sapling-inc.com
SAM Series 2-Wire and 3-Wire Clocks
Table of Contents
Table of Contents 2
Important Safety Instructions 3
Identify Your Clock 4
Wall Mount Installation - Round Metal Clock 5 - 8
- Round SlimLine Clock 9 - 12
- Round Aluminium/Wood Clock 13 - 17
- Square Clock 18 - 21
Flag Mount Installation - Round Metal Clock 22 - 28
- Round SlimLine/Aluminum Clock 29 - 35
- Square Clock 36 - 41
Double Mount Installation - Round Metal Clock 42 - 46
- Round SlimLine/Aluminum Clock 47 - 52
- Square Clock 53 - 59
Wiring Information - 2-Wire Digital Communication 60
- 3-Wire Synchronous (Sync-Wire) Communication 115/230VAC 61
- 3-Wire Synchronous (Sync-Wire) Communication 24VAC 62
Frequently Asked Questions 63
Questions about Protocols 64
Troubleshooting 65
Diagnostic #1 - Protocol Verification 66 - 67
Diagnostic #2 - Comprehensive Test 68 - 69
Diagnostic #3 - Manufacturing Default 70 - 71
Warranty 72
Manuals may change without prior notice
