Sargent Electrical Services Ltd. Copyright 2005
Issue 03 Page 5 of 11 12 May 2005
3.5 FUSE / MCB TABLE
WARNING
When replacing fuses always replace a fuse with the correct value. NEVER replace with a higher value /
rating as this could damage the wiring harness. If a replacement fuse ‘blows’ do not keep replacing the
fuse as you could damage the wiring harness. Please contact your dealer.
Fuse Rating Fuse Colour Wire Colour Description
1 15 Amps Blue Slate Front Lights
2 15 Amps Blue Pink Rear Lights
3 10 Amps Red Yellow / White 12v Sockets
4 10 Amps Red Black / tracer Fans
5 5 Amps Tan Yellow / Green Heater / Hob / Other Ignitions (if fitted)
6 5 Amps Tan Slate / Red Aux / Awning Light
7 10 Amps Red
Green / tracer
Purple
Water Pumps / Toilet
8 20 Amps Yellow * Charger (internally connected)
Battery 20 Amps Yellow Brown / Blue Fuse remotely located near battery
MCB Rating Wire Colour Description
1 10 Amps White 240v Sockets
2 10 Amps White (Yellow for heater) Extra 240v Sockets / Heater
3 6 Amps Black (Blue for water heater) Fridge / Water Heater / 12v Charger
(internally connected)
