Data Output Format with 16 Characters
Display segments that are not activated are output as spaces.
The type of character that can be output depends on the character’s position:
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ DDDD DDD * UUUCRLF
or – . . . . . . . * * *
or * ***** ***
*: Space CR: Carriage return
D: Digit or letter LF: Line feed
U: Unit symbol .: Decimal point
Special Codes
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
******* *******CRLF
or H i g h
or L o w
or C a l . E x t .
*: Space High: Overload
Cal. Ext.: Calibration, external Low: Underload
Error Codes
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Err*###****CRLF
APP . ERR
1
)* * * *CRLF
DIS. ERR
1
)* * * *CRLF
PRT . ERR
1
)* * * *CRLF
*: Space # # #: Error number
1
) See “Troubleshooting Guide”
