Model ED8201 | GW7201 ED5201 | ED2201 |
ED8201-CW ED5201-CW ED2201-CW
Weighing capacity g 8200 7200 5200 2200
Readability g 0.1 0.1 0.1 0.1
Tare range (subtractive) g 8200 7200 5200 2200
Repeatability (std. deviation) <±g 0.1 0.1 0.1 0.1
Linearity <±g 0.1 0.1 0.1 0.1
Response time (average) s 1 1 1 1
Sensitivity drift within <±/K 10 · 10
–6
+10 to +30°C
Adaptation to ambient By selection of 1 of 4 optimized filter levels;
conditions display update: 0.05–0.4 (depends on filter level selected)
External calibration weight
(of at least g 5000 (F2) 5000 (F2) 5000 (F2) 2000 (F2)
accuracy class...)
Net weight, approx.: kg 2.7 | 3.5 2.7 2.7 | 3.5 2.7 | 3.5
Weighing pan size mm 180 + 180
Dimensions (WxDxH) mm 230 + 303 + 91
56
