MOUNTING THE RECEIVER
1. Remove the screw from the bottom of thermostat. Gently pull
the control panel straight off the base. Forcing or prying on the
thermostat will cause damage to the unit.
2. Connect wires beneath terminal screws on power supply
module using appropriate wiring schematic. See figure 5
3. Push power base into 86mmX86mm conduit box.
4. Using two mounting screws mount the power base to the wall.
Place a level against bottom of base, adjust until level, and
