SATAjet 5000 B RP/HVLP PHASER Operating Instructions
SATAjet 5000 B RP/HVLP PHASER Operating Instructions
Information!
• Check spray pattern after cleaning the nozzle set!
• Further cleaning tips can be found at www.sata.com/TV.
9. Maintenance
Danger! Notice!
• Prior to maintenance, disconnect the spray gun from the compressed
air circuit!
• Disassemble and install components very carefully! Exclusively use
included special tools!
9.1. Replacing the Nozzle Set [7-1], [7-2], [7-3], [7-4], [7-5]
and [7-6]
Each SATA nozzle set consists of a "paint needle" [7-1], "air nozzle ring"
[7-2], "air nozzle" [7-3] and "paint nozzle" [7-4] and is manually adjusted
for a perfect spray pattern. Use your hand to push the old air nozzle out
of the nozzle ring [7-5]. Grease the paint needle [7-1] around the nee-
dle seal (approx. 3 cm before the needle bush, paint needle spring) and
threading of the material ow control screw [1-11]. Always replace the
complete nozzle set. After assembly, set the material ow rate as instruct-
ed in Chapter 7.2.
9.2. Replacing the air distribution ring
Steps: [7-1], [7-
2], [7-3], [8-1], [8-2] [8-3], [7-6], [7-7] and [7-8]
Notice!
• Remove air distribution ring with SATA extraction tool only.
• Do not apply force to avoid damage of sealing surfaces.
