Satel APD-200 - Specifications

The APD-200 detector can detect motion in a protected area. It is designed for operation
within the ABAX 2 / ABAX two-way wireless system. This manual applies to the detector with
firmware version 1.00 (or newer), which is supported by:
 ABAX 2:
– ACU-220 / ACU-280 controller,
– ARU-200 repeater.
 ABAX:
– ACU-120 / ACU-270 controller (firmware version 5.04 or newer),
– ARU-100 repeater (firmware version 2.02 or newer),
– INTEGRA 128-WRL control panel (firmware version 1.19 or newer and firmware
version of processor used to operate ABAX system 3.10 or newer).
1 Features
 Dual element pyrosensor.
 Digital motion detection algorithm.
 Digital temperature compensation.
 Option to enable / disable the creep zone protection.
 Ability to replace the lens with a curtain or long-range one.
 Encrypted two-way radio communication in the 868 MHz frequency band (AES standard
for the ABAX 2 system).
 Transmission channel diversity – 4 channels for automatic selection of the one that will
enable transmission without interference with other signals in the 868 MHz frequency
band (ABAX 2 system only).
 Remote update of detector firmware (ABAX 2 system only).
 Remote configuration.
 Built-in temperature sensor (temperature measurement range from -10°C to +55°C).
 LED indicators.
 Supervision of motion detection system.
 “ECO” option for longer battery life (ABAX 2 system only).
 Battery status control.
 Tamper protection against enclosure opening and removal from mounting surface.
 Adjustable mounting bracket included.
2 Specifications
Operating frequency band ...................................................................868.0 MHz ÷ 868.6 MHz
Radio communication range (in open area)
ABAX 2
ACU-220 .............................................................................................. up to 2000 m
ACU-280 .............................................................................................. up to 1600 m
ABAX.............................................................................................................. up to 500 m
Battery ................................................................................................................... CR123A 3 V
Battery life expectancy.......................................................................................... up to 2 years
Temperature measurement range .......................................................................-10°C...+55°C
