6 APD-200 SATEL
11. Fasten the electronics module in the enclosure.
12. If the detector is to protect the creep zone, the knob located on the inner side of the
enclosure cover is to be set in position shown in Fig. 6-A. If the detector is NOT to protect
the creep zone, set the knob to the position shown in Fig. 6-B.
13. Replace the cover.
14. Configure the detector settings (sensitivity of PIR sensor, etc. – see the ABAX 2 / ABAX
controller manual / the INTEGRA 128-WRL control panel manual).
