2 AXD-200 SATEL
The AXD-200 detector is designed for operation within the ABAX 2 / ABAX two-way wireless
system. It is a device that can be used as magnetic contact, shock, reorientation,
temperature or flood detector. In the ABAX 2 system, it can also be used as a hardwired
zone expander. You can select the type of device before or while adding it to the system
(see “Selecting device type”). Table 1 shows how the device is identified in the wireless
system, depending on the selected type.
Device name in the system
Device type
ABAX 2
ABAX
AMD-200
AMD-100
Magnetic contact
AMD-201
AMD-101
Dual channel magnetic contact
AMD-202
AMD-102
Magnetic contact with input for roller shutter
detector
AVD-200
AVD-100
Shock detector and magnetic contact
ARD-200
ARD-100
Reorientation detector
ATD-200
ATD-100
Temperature detector
AFD-200
AFD-100
Water flood detector
ATX-220
Hardwired zone expander: 2 x NC
ATX-230
Hardwired zone expander: NC and roller shutter
Table 1.
The device with factory default settings is identified in the ABAX 2 system as the AMD-200
detector, and in the ABAX system as AMD-100.
This manual applies to the device with firmware version 1.05, which is supported by:
• ABAX 2:
– ACU-220 / ACU-280 controller (firmware version 6.08 or newer),
– ARU-200 repeater.
• ABAX:
– ACU-120 / ACU-270 controller (firmware version 5.04 or newer),
– ARU-100 repeater (firmware version 2.02 or newer),
– INTEGRA 128-WRL control panel (firmware version 1.20 or newer and firmware
version of processor used to operate ABAX system 3.10 or newer).
The temperature detector (ATD-200) is not supported by the controller connected to
the VERSA / VERSA Plus / VERSA IP control panel.
The ATX-220 and ATX-230 hardwired zone expanders are not supported in the ABAX
system.
The ATX-220 and ATX-230 hardwired zone expanders are supported by the INTEGRA
control panels with firmware version published after 2 January 2022 (1.20 or newer).
