FUNCTIONAL DESCRIPTION
19
software consists of two parts: The STARTER program designed for programming
the FLASH memory, and the control panel program. When the program STARTER
runs, the control panel normal functions are deactivated (status of electronic circuit
protectors only is monitored).
When the program STARTER runs, the LED at the telephone line relay quickly blinks
and a proper message is displayed at all LCD keypads. Program STARTER does not
operate partition keypads, and their LEDs light in sequence: from most top one to the
lowest one.
The STARTER program may be triggered to the programming mode in two ways:
1) By calling it from the service mode function menu.
2) By switching on the control panel power supply with RESET pins shortened.
Remove jumper immediately after the control panel has switched on power supply
at outputs supplying keypads and expanders (when the jumper is not removed
before calling the control panel program by STARTER, downloading via RS-232
will be started or the control panel will trigger to the service mode).
NOTES:
• When program STARTER is in the programming mode, the message “STARTER
2.2 is running...” is displayed at LCD keypads. This informs on readiness to
operate with the FLASH64 program (it should be started in the computer
connected to the control panel main board via RS-232). If the STARTER program
receives no command from the computer within 2 minutes, the control panel
program will be restarted.
• When the control panel is connected to the computer, the STARTER program
may be stopped by calling the command “ Restart CA-64” in the FLASH64
program ( Ctrl-F2, then indicate the port, to which the control panel is connected)
CONTROL PANEL INSTALLATION
Control panel CA-64 should be installed in closed rooms with normal air humidity.
Permanent (not disconnectable) power supply 220 VAC with protective ground
should be available in this room. The telephone line must be made from four-wire
cable to make possible connection of the control panel to other equipment
(telephone, fax etc.).
NOTES
• Install main board fixing pins prior to the control panel housing installation.
• When installing the housing, pay attention not to damage cables to be put through
openings in control panel housing rear wall.
• The control panel main board and the expander modules need not be grounded.
• Switch off mains power supply and battery power supply when connecting LCD
keypads and other components powered from control panel outputs.
CAUTION!
Since the control panel is powered from 200VAC mains, carelessness when wiring or
incorrect wiring may lead to electric shock and danger to life!
Therefore, be very careful when wiring the control panel. The power supply cable
cannot be live when installing and connecting it to the control panel!
