13.2 Specifications
Tuner
Frequency 950 ~ 2150MHz
Symbol Rates 2~45,000 (DVB-S) 2~45,000 (DVB-S2)
Level -65 ~ -25dBm
Impedance 75Ω
Connector IEC 169-24 Female
LNB Supply 13V/18V/OFF, 400mA max.
LNB Switch 22KHz
DiSEqC 1.0,1.1,1.2, USALS Compatible
Channel Decoding
Standard DVB-S EN300421 DVB-S2 EN302307
Demodulation QPSK, 8PSK
FEC Mode QPSK-1/2,2/3,3/4,5/6,7/8. 8PSK 1/2,2/3,3/4,3/5,4/5,5/6,8/9.
Processor & Memory
CPU STi-7111 450MHz
Flash 128MBytes
DDR 256MBytes
EEPROM 32 Kbyte
Demultiplexer
Standard ISO/IEC 13818-1
Audio Decoding
Standard ISO/IEC 13818-3
Channel Left, Right, Stereo, Dual Mono
Decoding MPEG-1 & MPEG-2 layer I and II (Musicam), MP3
Dolby AC3 MPEG-4 HE-AAC+ ISO/IEC 14496-3
Sampling Frequency 32,44.1,48 KHz
Video
Standard ISO/IEC-13818-2,MPEG-2MP@ML, MPEG-4 AVC/H.264 MP@L4.1
Resolution 1080i,720p,576p.576i
TV System PAL/NTSC
Aspect 4:3,16:9
RF Modulator
Channels 21~69 (470~860MHz)
