SatKing PRO MAX User manual - 10
3-3. Quick reference
When you physically move SatKing PRO MAX, the unit must be returned to
HOME position to prevent damage.
WARNING
SatKing PRO MAX will be automatically folded back to HOME position if
vehicle moves faster than 10km/h when the unit is powered.
NOTE
You may need to wait 30 seconds while the receiver smartcard updates.
NOTE
Error message LED will be illuminated and the error message detail will be shown on LCD display, this will
detail if there is a problem with main unit.
i.
5. Special function 2 : ERROR MESSAGE
HOME POSITION error
If antenna does not come back to HOME position within the allowed time or the system does not
recognise HOME position despite the antenna being back at HOME position (The Limit sensor is
faulty).
ii. TUNNER error
If there is no response when searching the satellite due to a faulty tuner or its settings.
iii. MOVEMENT error
If the PRO MAX cannot move to correct position for some reason.
iv. COMMUNICATION error
If connection is lost between the PRO MAX and controller that lasts longer than 5 seconds.
TEST mode can be initialised when either an error message is shown or the antenna is at HOME position.
i.
ii.
iii.
6. Special function 3 : TEST mode
Press MODE once to enter TEST mode and press OK.
Go to “AZIMUTH - ELEVATION - SKEW - ALL MOTORS - GPS Information– FW Ver” using the arrow
buttons and press OK to select.
To exit, press MODE and PRO MAX will return to previous status.
1.
2.
3.
Press POWER to turn on the unit and select a satellite using arrow buttons and press OK
Wait until “SAT FOUND” is displayed on LCD and NID check (second LED on the left side)
becomes solid.
Now, the selected satellite has been locked and the TV channels will be shown on TV.
