Eyr GNSS RTK System User Manual
Figure 2-1-3
1. Type-C USB interface 2. Connection screw 3. Speaker 4. SMA antenna interface
◇
Type-C USB interface: To upgrade the firmware and download static data.
◇
SMA antenna interface: Connect the radio antenna while using the Internal UHF mode.
◇
Protective plug: Used for dustproof and waterproof sockets.
Notice:
1.If you don’t use the SMA antenna interface and USB interface, please cover the
rubber plug to protect them from dust and water.
2.When the speaker is flooded, the sound may be silent or hoarse, but it will return
to normal after it has dried.
2.1.3 Control cover
The control panel includes a satellite light, power button and data light.
