SatLab Eyr - Information

Eyr GNSS RTK System User Manual
www.satlab.com.se 20
Base
Data link and parameter settings of the base
Static
Static measurement parameter settings
File manager
Static data
Download, delete and format static data
Firmware
Upgrade
Select and upgrade the firmware
Restore
Restore the system
System
Constellation
The satellite tracking switches
Radio
Radio frequency list
Registration
Device registration and information
Reset
Reset the motherboard
Others
Switch of the static RINEX and volume control, etc
Coordinate
System
Projection
Modify projection model, central meridian, scale
factor, etc.
Datum
Modify source ellipsoid, target ellipsoid and
transformation model
DAM File
Export/import of coordinate system parameters in
dam format
2.3.2 Information
1. Device information
Includes the main information about the device: device model, S/N, firmware version, OEM info,
battery power, work mode, configuration parameters, etc.
Figure 2-3-9 Device information
2. Position information
