Satlink WS 6951 - Page 8

Digital Satellite Finder
4
NO Description FUNCTION
1 LNB IN Connect to satellite antenna cable
2 USB Port Connect to USB memory
3 DC Slot Connect to Adaptor Input
4 HDMI Use HDMI cable to connect for TV
5 AV IN Connect to AV port for meter
6 AV OUT Connect to AV port for TV
7 DC12V Slot DC12V OUT
8 Power witch Turn on/o󱐯 meter
9 Speaker Speaker Integrated
10 Torch LED Night lighting
11 0-9 Number key to select channels or enter
programming
12 NEVIGATION
KEY
Volume Control or move cursor, chan-
nel or change, conrm etc
13 BLUE &AUDIO Blue key & Audio interface
14 Orange &TV/R Orange key & TV and radio switch
15 Green & SUBT Green key & Subtitle interface
16 Red & TTXT Red KEY &Teletext interface
17 INFO INFO key
18 AV-S If we connect AV IN; switch AV in/out
for LCD and speaker
19 MUTE MUTE
20 SCAN ‘Quick Search’menu shortcut key
21 EXIT Escape from present menu and save
the settings
22 MENU Show the main menu on the screen or
jump back to previous menu in sub-
menu setting conditions
