23 Charger (Note1) Charger indicator light
24 LOCK Signal lock indicator light
25 V/H Vertical /Horizontal polarization volta-
ge output light
26 22KHZ 22Khz indicator light
27 Power Power indicator light
28 LCD TFT LCD Screen
Note1:When the adapter insert dc slot, Charge indicator is red,
when the batteries charged su󱐰cient, the charge indicator is
orange.
1.4 INSTALLATION OFMETER
