MMI WITH BASE MEASUREMENT OF THE FLAME SIGNAL
IRD 1020
MMI 810.1 / 811.1
HOLDER M93
30
30
24
67
91
87
24
Reset button
Slide-in plate
PG 11
61
ø 16 mm,
cable entry from below
57-60
30
3525
44
16
M4
16
Earth
5
MMI 810.1 / MMI 811.1
2
E
+
-
ORDERING INFORMATION
ITEM DESIGNATION ITEM NO.
Control unit Type MMI 810.1 mod. 33 0620220
or Type MMI 811.1 mod. 35 0621120
Base for MMI 810.1 Base 701 TTG-EN 70101
Base for MMI 811.1 Base 710 TTG-FN 70102
Slide-in plate PG-plate 70502
optionally Cable clamping plate 70501
Flame detector IRD 1020 end-on viewing 16522
Flame detector IRD 1020 side-on left 16523
Flame detector IRD 1020 side-on right 16521
IRD mounting flange IRD Holder M93 59093
Flame detector cable 3-wire, 0.6 m 7236001
The above ordering information refers to the standard version.
Special versions are also included in our product range. Specifications subject to change without notice.
104
50
44
29
21.8
ø13.5
The signal should
be greater than 5 µA
0 - 10 µA
0 - 100 µA
The Satronic Ionimeter
is ideal for making
this measurement.
35
3
14
4.5
26
15.1
48
17
ø20.5
4

Satronic 0620720 Specifications

General

Brand	Satronic
Model	0620720
Category	Control Unit
Language	English
