2.0L L4 Supercharged Engine
Fuses Usage
1 Engine Control Module
2 Not Used
3 Not Used
4 Passenger’s Side Headlamp
5 Air Conditioning
6 Not Used
7 Not Used
8
Anti-lock Brake System, Traction
Control Module
9 Engine Control Module
Fuses Usage
10
Canister Purge Solenoid, Canister
Vent Solenoid, Low Coolant Switch,
Oxygen Sensors
11
Electric Ignition Control Module,
Charging System, Neutral Stop
Back-Up Switch
12 Not Used
13 Engine Control Module
14 Boost
15 PRNDL, Back-up Switch
16 Fuel Injectors
17 Not Used
18 Driver’s Side Headlamp
19 Windshield Wiper
20 Horn
21
Entertainment, Premium Radio
Amplifier
22
Anti-lock Brake System, Traction
Control Module
23 Rear Defogger
38 Starter/Ignition
39 Body Control Module 1
40
Anti-lock Brake System, Traction
Control Module
41 Body Control Module 2
5-98
