Underhood Fuse Block
The underhood fuse block is located in the engine
compartment on the passenger’s side of the
vehicle.
Lift the cover for access to the fuse block.
To remove fuses, use the fuse puller, or hold the
end of the fuse between your thumb and index
finger and pull straight out.
See Engine Compartment Overview on page 242
for more information on location.
Fuses Usage
1 Empty (LE5); Cooling Fan (LNF)
2 Rear Window Defogger
3 Empty
4 Body Control Module 3
5 Crank
6 Body Control Module 2
7 Body Control Module
8 Cooling Fan 2 (LE5); Empty (LNF)
9 Empty
328
