Fuses Usage
43
Engine Control Module,
Transmission
44 Anti-lock Brake System
45
Injectors, Ignition Coils (LE5);
Ignition Coils (LNF)
46
Back-up Lamps
(Manual Transmission);
Empty (Automatic Transmission)
47 Empty
48 Daytime Running Lamps Relay
49 Daytime Running Lamps
50
Cooling Fan 1 Relay (LE5);
Empty (LNF)
51 Run/Crank Relay
52 Windshield Wiper Low/High Relay
53 Fog Lamps
54 Fog Lamps Relay
55 Horn Relay
56
S Band, OnStar
®
, Remote
Keyless Entry System
Fuses Usage
57 Anti-lock Brake System
58 Wiper Diode
59 Windshield Wiper
60 Horn
61 Anti-lock Brake System
62 Instrument Panel Ignition
63 Driver’s Side High Beam
64 Canister Vent
65 Driver’s Side Low-Beam Headlamp
66
Passenger’s Side Low-Beam
Headlamp
67
Passenger’s Side High-Beam
Headlamp
68 Parking Lamps Relay
69 Parking Lamps
70 Windshield Wiper On/Off Relay
71 Low-Beam Headlamp Relay
72 High-Beam Headlamp Relay
330
