8
1. To confirm the punching position, hold the Wall Mount Shelf firmly and
use the screw holes to guide positioning. It is recommended to lift the
Wall Mount Shelf 130cm off the ground.
2. Use a hole drill (user-supplied) with a drill bit of 5mm to make holes at the
confirmed hole positions.
3. Insert the expansion pin into the holes, move the wall mount to the
corresponding position, then use a Phillips head screwdriver to tighten
the screws in the wall mount holes.
4. Adjust the wall mount to ensure it remains vertical, then tighten the
screws to complete the installation of the wall mount.
5. Insert the DC plug of the power adapter into the charging port on the top
of the battery.
Install wall mount
To Next Page
