Sauder 402375 - Step 6: Attach Top Panel and Modesty Panel

å
Fasten the ENDS (A2 and B) and UPRIGHTS (C2 and D2) to the
TOP (E3). Tighten eight HIDDEN CAMS.
å
Fasten the MODESTY PANEL (F2) to the UPRIGHTS (C2 and D2).
Use four BLACK 1-7/8" FLAT HEAD SCREWS (AAA).
Step 6
402375www.sauder.com/services
Page 11
Arrow
Minimum
190 degrees
Maximum
210 degrees
A2
C2
E3
F2
D2
B
This hole must be here.
BLACK 1-7/8" FLAT HEAD SCREW
(4 used for the MODESTY PANEL)
AAA
Meet Part (E3). This component has
been engineered to be lighter, stronger,
faster… well ok. Not technically faster. But
defi nitely makes for a sturdier Computer
Desk that’s easier to assemble and
friendlier to the environment.
