Sauder 408726 - Step 1: Initial Cam Assembly; Hidden Cam Tightening Caution

1
1
S
t
e
p
Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
Assemble your unit on a carpeted fl oor or on the empty carton to avoid scratching your unit or the fl oor.
Push ten HIDDEN CAMS (S2) into the ENDS (A2, B, and C), UPRIGHT (D2), SMALL UPRIGHT (E2), and SMALL BACK (K2).
Then, insert the metal end of the CAM DOWEL (T2) into each HIDDEN CAM.
Do not tighten the HIDDEN CAMS in this step.
(10 used)
B
C
A2
D2
E2
K2
Page 5
www.sauder.com/services408726
Arrow
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
S2
T2
