Sauder 408995 - Step 5: Attach Bottom Panel

å
Insert two METAL PINS (1R) into the BOTTOM (E).
å
Insert the METAL PIN (1R) in one end of the BOTTOM (E)
into the hole in the LEFT END (B).
å
Fasten the BOTTOM (E) to the LEFT END (B). Tighten the
HIDDEN CAM.
Step 5
1R
B
E
Long edge with CAM DOWELS
Surface with
HIDDEN CAMS
Arrow
Minimum
190 degrees
Maximum
210 degrees
408995 www.sauder.com/servicesPage 10
