Sauder 408995 - Step 6: Connect Upright and Shelf

å
Fasten the UPRIGHT (C) to the BOTTOM (E) and
SHELF (G). Tighten three HIDDEN CAMS.
å
NOTE: Be sure the METAL PIN in the BOTTOM (E)
inserts into the hole in the UPRIGHT (C).
Step 6
Arrow
Minimum
190 degrees
Maximum
210 degrees
Finished edge
Edge with CAM DOWELS
C
E
G
408995www.sauder.com/services
Page 11
