9
 Fasten the LOWER RIGHT END (C) to the BOTTOM (F) and SHELF (G). Tighten four HIDDEN CAMS.
 Slide the LOWER END MOLDINGS (P) onto the notched edges of the LOWER ENDS (C and D).
* U.S. Patent No. 5,499,886
Slide the LOWER END MOLDINGS (P)
onto the notched edges.
G
D
F
C
P
P
Maximum
210 degrees
Minimum
190 degrees
Arrow
