Sauder 412314 - Step 9: Main Structure Assembly; Shelves, Backs, and Ends to Structure

www.sauder.com/services
9
412314
 Fasten the SHELVES (E) and BACKS (F) to the UPRIGHTS (B and C). Use eight BLACK 1-7/8” FLAT HEAD
SCREWS (AA).
 Fasten the ENDS (A) to the TOP (D). Tighten four HIDDEN CAMS.
Maximum
210 degrees
Minimum
190 degrees
Arrow
B
C
E
FF
E
A
A
AA
BLACK 1-7/8” FLAT HEAD SCREW
(8 used in this step)
D
G
H
I
J
