Sauder 412314 - Step 5: Leg and Support Assembly; Legs to Ends and Moldings Connection

Sauder 412314
28 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
www.sauder.com/services
5
Edge with CAM
DOWELS
412314
Fasten the LEGS (G, H, I, and J) to the ENDS (A) and SHELF MOLDINGS (P). Tighten eight HIDDEN CAMS.
A
P
A
P
G
H
I
J
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Edge with CAM
DOWELS
