Step 1
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å
Assemble your unit on a carpeted fl oor or on the empty
carton to avoid scratching your unit or the fl oor.
å
Push twelve HIDDEN CAMS (Q) into the ENDS (A and B),
LOWER ENDS (C and D), and BOTTOM (F). Then, insert the
metal end of a CAM DOWEL (R) into each HIDDEN CAM.
414356www.sauder.com/services
Page 5
Arrow
Q
R
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
(12 used)
A
B
C
D
F
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1585
to watch a video on how to assemble your unit.
